| Quantity: | |
|---|---|
| Model | XH7136 |
| Main motor | 5.5KW (Standard Accessories：Frequency Conversion Motor) |
| Spindle taper | Servo Spindle 6000rpm |
| Spindle speed | 200-8000rpm (4000rpm optical accessories) |
| Distance of spindle end to worktable plane | 100～600 mm |
| Distance of spindle hole center to column plane | 460 mm |
| Worktable size | 1250×360 mm |
| Worktable travel (L/H) | 900/350 mm |
| Max. load of worktable | 400kg |
| Worktable T Slot: No./Width/Interval | 3/18/80 |
| Max. Movement: X Axis | 10 m/min |
| Max. Movement: Y Axis | 10m/min |
| Max. Movement: Z Axis | 8 m/min |
| Positioning Accuracy | 0.02mm |
| Repeatable Positioning Accuracy | 0.01mm |
| Machine Dimension (L×W×H) | 3300×2280×2550 mm |
| Machine Weight | 4200 kg |
| Model | XH7136 |
| Main motor | 5.5KW (Standard Accessories：Frequency Conversion Motor) |
| Spindle taper | Servo Spindle 6000rpm |
| Spindle speed | 200-8000rpm (4000rpm optical accessories) |
| Distance of spindle end to worktable plane | 100～600 mm |
| Distance of spindle hole center to column plane | 460 mm |
| Worktable size | 1250×360 mm |
| Worktable travel (L/H) | 900/350 mm |
| Max. load of worktable | 400kg |
| Worktable T Slot: No./Width/Interval | 3/18/80 |
| Max. Movement: X Axis | 10 m/min |
| Max. Movement: Y Axis | 10m/min |
| Max. Movement: Z Axis | 8 m/min |
| Positioning Accuracy | 0.02mm |
| Repeatable Positioning Accuracy | 0.01mm |
| Machine Dimension (L×W×H) | 3300×2280×2550 mm |
| Machine Weight | 4200 kg |
