SG618A/SG818A Manual Surface Grinder

Quantity:
  • SG618A/SG818A
  • FICOM
Overview

· Widely useful, grind various surface.

· Spindle and leadscrew is imported.

· Rolling ball guideway is used on longitudinal direction.

· Double V type guideways.

· Vertical handwheel is fixed on bed.

· Manual oil pump lubricates all moveable parts.

SG618A


Technical Parameters
Model No. SG618A SG818A
max. width to be ground 165mm 220mm
max. length to be ground 470mm 470mm
max. height to be ground 350mm 350mm
work table size 155×460mm 210×450mm
permanent magnetic chuck size 150×400mm 200×450mm
max. longitudinal travel 500mm 500mm
max. cross travel 185mm 240mm
max. distance from spindle to table surface 450mm 450mm
feed of vertical handwheel 1per rev. 1per rev.
grinding wheel size(OD×W×ID) 200×13×31.75mm 200×13×31.75mm
spindle speed 3450(60Hz)2850(50Hz) r/min 3450(60Hz)2850(50Hz) r/min
power of spindle head 1.5Kw 1.5Kw
max. load capacity 97Kg 128Kg
packing size 1340×1120×1930mm 1400×1120×1985mm
N.W. 720Kg 800Kg


Standard Accessories
wheel balancing arbor hoisting set spanner
wheel chuck wheel dresser levelling screw and block tool box and special wrench
halogen lamp coolant system


Optional Accessories
permanent magnetic chuck dust collector wheel balancing stand cooling and dust collecting equipment
