RD3210/RD4010/RD5016/RD5020/RD6320/RD8025
FICOM
· Protection design for limitary satety is utilized in all transmission section.
· All controls centralized on the headstock for easy operation and change.
· Main parts are made by machine center with high precison and efficiency.
· Integrating technology for casting parts is excellent, ensuring high quality of material for basic parts.
· Spindle parts are made by special high quality steel, heat treatment to be made by first class equipments,ensuring high strength and durabililty.
· Ground gears inside, ensuring high precision and low noise.
| Model No. | RD3210/RD4010 | RD5016/RD5020 | RD6320 | RD8025 |
| max. drilling capacity | 32/40mm | 50mm | 63mm | 80mm |
| distance from spindle to column | 300-1000mm | 350-1600/350-2000mm | 450-2050mm | 500-2050mm |
| diameter of column | 240mm | 350mm | 450mm | 550mm |
| spindle taper | MT4 | MT5 | MT5 | MT6 |
| spindle travel | 280mm | 315mm | 400mm | 450mm |
| spindle speed range | 32-2500mm | 25-2000mm | 200-1600mm | 16-1250mm |
| spindle speed steps | 16 | 16 | 16 | 16 |
| range of spindle feed | 0.10-1.25mm | 0.04-3.2mm | 0.04-3.2mm | 0.04-3.2mm |
| step of spindle speed | 8 | 16 | 16 | 16 |
| distance from spindle nose to table | 220-1000mm | 320-1220mm | 400-1600mm | 550-2000mm |
| dimension of worktable | 600×450×450mm | 630×500×500mm | 950×630×500mm | 1000×800×560mm |
| dimension of base | 1710×800×160mm | 2400×1000×200mm | 2900×1250×250mm | 3530×1400×300mm |
| packing size | 1870×970×2200mm | 2600×1120×2600mm | 3470×1470×2350mm | 4160×1650×2480/3820×1630×1700mm |
| power of main motor | 2.2Kw | 5.5Kw | 5.5Kw | 7.5Kw |
| G.W./N.W. | 2000/1600Kg | 3900/3500Kg | 8000/7000Kg | 15000/11000Kg |
| rise block | taper sleeve | tool releasing wrench | drift |
| eyelet bolts | box work table |
| quick instead chuck | tapping chuck | angle work table | |
