PB25/1320 CNC Press Brake

Availability:
Quantity:
Inquire Add to Basket

  • PB25/1320

  • FICOM

Overview



PB25

Technical Parameters
Model No.
 Unit PB25/1320
nominal force
 Kn 250
working table length
 mm 1320
distance between frames mm 1030
throat depth
 mm 200
ram travel mm 120
max open height between table and ram
 mm 320
ram travel adjustment mm 60
ram travel speed no-load cyclic index mm/s 36
working speed mm/s 10
return speed mm/s 80
main motor
 model
Y112M-6 B35
horse power Kw 5.5
speed r/min 1440
ram adjustment
 model
YS7114-4  B3
horse power Kw 0.25
speed r/min 1440
back gauge adjustment
 model
Y802-6 B3
horse power Kw 0.55
speed r/min 960
gear pump
 pressure Mpa 32
flow L/min 10
model
NT-G10F
max working pressure of hydraulic system
 Mpa 20
overall dimensions
 length mm 1830
width mm 910
height mm 1500
G.W.
 Kg 2200
