Availability: | |
---|---|
Quantity: | |
Model No. | MIW50 | MIW55 | MIW60 | |
punching | max. capacity | 1" dia. in 5/8" plate | 1-1/16" dia. in 5/8" plate | 1" dia. in 3/4" plate |
flat bar shearing | max. width | 1/2"×10" | 1/2×12" or 3/8"×14" | 1/2×12" or 3/8"×14" |
max. thickness | 3/4"×4" | 3/4"×4" | 3/4"×4" | |
angle shearing | max. size | 4"×4"×1/4" or 3"×3"×3/8" | 4"×4"×1/4" or 3"×3"×3/8" | 4"×4"×3/8" or 3"×3"×1/2" |
coper notcher | max. capacity | - | - | 1-1/2"×5"×1/4" |
max. thickness | - | - | 2-1/2"×4"×3/8" | |
rated capacity | 50t | 55t | 60t | |
throat depth | 7" | 7-1/2" | 7-1/2" | |
open height | 8×1/8" | 8" | 8" | |
shut height | 7" | 6-3/4" | 6-3/4" | |
stroke | 1-1/8" | 1-1/4" | 1-1/4" | |
motor power | 5HP | 5HP | 5HP |
Model No. | MIW50 | MIW55 | MIW60 | |
punching | max. capacity | 1" dia. in 5/8" plate | 1-1/16" dia. in 5/8" plate | 1" dia. in 3/4" plate |
flat bar shearing | max. width | 1/2"×10" | 1/2×12" or 3/8"×14" | 1/2×12" or 3/8"×14" |
max. thickness | 3/4"×4" | 3/4"×4" | 3/4"×4" | |
angle shearing | max. size | 4"×4"×1/4" or 3"×3"×3/8" | 4"×4"×1/4" or 3"×3"×3/8" | 4"×4"×3/8" or 3"×3"×1/2" |
coper notcher | max. capacity | - | - | 1-1/2"×5"×1/4" |
max. thickness | - | - | 2-1/2"×4"×3/8" | |
rated capacity | 50t | 55t | 60t | |
throat depth | 7" | 7-1/2" | 7-1/2" | |
open height | 8×1/8" | 8" | 8" | |
shut height | 7" | 6-3/4" | 6-3/4" | |
stroke | 1-1/8" | 1-1/4" | 1-1/4" | |
motor power | 5HP | 5HP | 5HP |
