FICOM
| No. | items | unit | main specification |
| 1 | material thickness | mm | 0.4-0.6 |
| 2 | forming speed | m/min | 12-15 |
| 3 | roll station | / | 19 stations (depend on the profile) |
| 4 | main power | kw | 4 |
| 5 | hydraulic power | kw | 5.5 |
| 6 | control system | / | PLC panasonic |
| 7 | drive | / | by chain |
| 8 | curving and interlocking | / | separate cuving and interlocking equipment |
| 9 | maximum curving angle | ° | 90 |
| No. | items | unit | main specification |
| 1 | material thickness | mm | 0.4-0.6 |
| 2 | forming speed | m/min | 12-15 |
| 3 | roll station | / | 19 stations (depend on the profile) |
| 4 | main power | kw | 4 |
| 5 | hydraulic power | kw | 5.5 |
| 6 | control system | / | PLC panasonic |
| 7 | drive | / | by chain |
| 8 | curving and interlocking | / | separate cuving and interlocking equipment |
| 9 | maximum curving angle | ° | 90 |
