DN4025 Bench Drilling Machine / DN5025 Column type of Vertical Drilling Machine

Availability:
  • DN4025/DN5025

  • FICOM

Overview

DN4025



Technical Parameters
Model No. DN4025 DN5025
max. drilling diameter(steel) φ25mm φ25mm
max. tapping diameter M16 M16
max.travel of spindle 110mm 110mm
max.distance from spindle to generating line of column 240mm 240mm
max.distance between spindle end to the worktable surface - 630mm
max.distance from spindle end to the surface of  base worktable 650mm 1100mm
max. travel of spindle box 500mm 250mm
max. travel of worktable and bracket - 450mm
spindle taper bore MT3 MT3
spindle speed steps 6 6
spindle speed range 125~2825r/min 125~2825r/min
dimension of worktable - 350×400mm
effective working area of worktable 310×320mm 310×320mm
diameter of column φ95mm φ95mm
power of motor 0.75Kw 0.75Kw
machine dimension 700×500×1500mm 700×500×1900mm
N.W./G.W. 230/280Kg 300/350Kg
mode of spindle feed Manual Manual
