Made from polyester according to EN 12195-2:2000.
Material: 100% high-strength polyester yarm.
Color: orange, blue, yellow, red, black.
Safety factor: 2:1.
Cargo lashing is not allowed to use for lifting purposes!
Permissible Pulling Force (lc) | 10t, two-piece system 402100 | |||
Fperm: 5,000 daN | Tensioning element: pressure ratchet Standard length: 10.0m, of which fixed end (FE): 0.7m | |||
Fperm: 10,000 daN | ||||
Connecting element (VE) | Part Number | |||
Claw hook | 202100-CH | |||
J hook, double | 202100-JD | | ||
Flat hook | 202100-FH |
Permissible Pulling Force (lc) | 5t, two-piece system 402050 | |||
Fperm: 2,500 daN | Marked with 5 woven stripes Tensioning element: pressure ratchet Standard length: 8.0m, of which fixed end (FE): 0.5m | |||
Fperm: 5,000 daN | ||||
Connecting element (VE) | Part Number | |||
Twisted snap hook | 202050-TS | |||
J hook, double | 202050-JD | | ||
J hook, double with keeper | 202050-JK | |||
Claw hook | 202050-CH |
