CP / CPD
FICOM
| Model | Unit | CP15 FTH | CP15 FT | CP18 FTH | CP18 FT | CPD20 FTH | CPD20 FT | CPD25 FTH | CPD25 FT | CPD30 FTH | CPD30 FT | CPD35 FTH | CPD35 FT |
| Power Type | BATTER | ||||||||||||
| Rated Capacity | kg | 1500 | 1800 | 2000 | 2500 | 3000 | 3500 | ||||||
| Load Centre | mm | 500 | |||||||||||
| Lift Height | mm | 30 | |||||||||||
Free lifting height | mm | 120 | 100 | 100 | |||||||||
Fork Size (L×W×T) | mm | 920×100×40 | 1070×120×40 | 1070×125×45 | 1070×125×50 | ||||||||
| Mast Tilt Angle(F/R) | Deg | 6°/12° | |||||||||||
Overall length (Without fork) | mm | 2075 | 2280 | 2530 | |||||||||
| Overall Width | mm | 1080 | 1150 | 1220 | |||||||||
Mast Lowered Height | mm | 1995 | 1995 | 2025 | |||||||||
Mast Extended Height (With backrest) | mm | 3995 | 4020 | 4250 | |||||||||
Overhead Guard Height | mm | 2170 | 2220 | 2220 | |||||||||
Min. Turning Radius | mm | 1920 | 2100 | 2300 | |||||||||
| Front overhang | mm | 413 | 485 | 500 | |||||||||
Speed Travel (Full/NO load) | km/h | 10.5/11 | 13/13.5 | 11/12 | |||||||||
Speed Lifting (Full/NO load) | m/s | 0.28/0.45 | 0.3/0.45 | 0.28/0.45 | 0.3/0.45 | 0.28/0.45 | 0.3/0.45 | 0.28/0.45 | 0.3/0.45 | 0.22/0.37 | 0.23/0.37 | 0.22/0.37 | 0.23/0.37 |
Max. Gradeability (Full/NO load) | % | 10.5/14 | 10.5/14 | 10.5/12 | |||||||||
| Service Weight | kg | 3450 | 3650 | 4400 | 4600 | 4980 | 5100 | ||||||
| Front Tire | 6.50-10-10PR | 7.00-12-12PR | 28*9-15-12PR | ||||||||||
| Rear Tire | 5.00-8-8PR | 18*7-8-14PR | 18*7-8-14PR | ||||||||||
| Wheelbase | mm | 1280 | 1500 | 1625 | |||||||||
Min. Ground Clearance (Bottom of mast/full load) | mm | 110 | 110 | 130 | |||||||||
Battery Voltage/ Capacity | V/Ah | 48/400 | 48/500 | 48/630 | 80/500 | ||||||||
Drive unit Traveling motor | kw | 8 | 11 | 11.75 | |||||||||
Drive unit Lifting motor | kw | 7.5 | 11 | 7.5 | 11 | 8.6 | 8.6 | 10 | 8.6 | 13 | 10 | 13 | 10 |
Electric Controller Manufacturer | ZAPI | ||||||||||||
Electric Controller Type | AC | ||||||||||||
