BQ1022/BQ1126
FICOM
· The bed way is hardened and ground. It features with super pome accuracy and well wear-resisting.
· The main spindle is mounted on 2 precision accuracy taper roller bearings.
· The hole through main spindle is 26mm and the highest speed for main spindle is 2000r.p.m.
· Changing speeds by belt, The machine can operate at low noise.
| Model No. | BQ1022 | BQ1126 | ||
| max. swing over bed | 254mm | 10" | 280mm | 11" |
| max. swing over cross slide | 156mm | 49/8" | 182mm | 57/8" |
| max. length of workpieces | 550mm | 22" | 660mm | 26" |
| taper of spindle bore | M.T.No.4 | M.T.No.4 | M.T.No.4 | M.T.No.4 |
| spindle bore | 26mm | 1" | 26mm | 1" |
| range of spindle speed | 125-2000rpm(50Hz) | 125-2000rpm(50Hz) | ||
| 125-2400rpm(60Hz) | 150-2400rpm(60Hz) | |||
longitudinal feed per revolution of spindle | 0.063-0.35mm/rev | 0.0025"-0.013"/rev | 0.063-0.35mm/rev | 0.0025"-0.013"/rev |
range of inch threads | 8-72T.P.I(32kinds) | 8-72T.P.I(32kinds) | ||
| maximum tool size | 0.25-3.5mm(18kinds) | 0.25-3.5mm(18kinds) | ||
| range of metric threads | 12×12mm | 0.5"×0.5" | 12×12mm | 0.5"×0.5" |
| dia. of tailstock sleeve | 32mm | 1.25" | 32mm | 1.25" |
| taper of tailstock sleeve bore | M.T.No.2 | M.T.No.2 or No.3 | ||
| max. travel of tailstock sleeve | 65mm | 2.5" | 65mm | 2.5" |
| motor power | 0.75Kw(1HP) | 0.75Kw(1HP) | ||
| motor frequency | 50Hz or 60Hz | 50Hz or 60Hz | ||
| N.W. | 150Kg | 180Kg | ||
| packing size(L×W×H) | 140×57×56.5cm | 55"×139/6"×22.25" | 140×57×63cm | 55"×139/6"×24.75" |
| G.W. | 2000Kg | 2300Kg | ||
3 jaws & 4 jaws chuck | face plate | steady rest | follow rest |
| toolbox & tools | micro carriage stop |
quick change tool post | turning tools | digital readout | leadscrew cover |
| chuck cover | stand & oil tray |
